Shadow Exploration 2021 1.5L Manual Shang Zhilian Edition
Polar White / black/gray
Bare car
VIN LFV2B*******30MSRP:¥115,900
Basic parameters
StandardOptional-None
- ManufacturerFAW-Volkswagen
- LevelSmall SUV
- Energy TypeGasoline
- Environmental standardsGo VI
- Launch time2021.01
- Maximum power (kW)83
- Maximum torque (N·m)145
- Engine1.5L 113 horsepower L4
- Transmission5-speed manual transmission
- Length*Width*Height (mm)4194*1760*1601
- Body structureSUV
- Maximum speed (km/h)185
- Official 0-100km/h acceleration (s)12.5
- NEDC Average Fuel Consumption (L/100km)6
- WLTC average fuel consumption (l/100 km)6.12
- Whole vehicle warranty3 years or 100,000 km
Body
StandardOptional-None
- Length (mm)4194
- Width (mm)1760
- Height (mm)1601
- Wheelbase (mm)2651
- Front Track Width (mm)1526
- Rear Wheel Track (mm)1504
- Minimum ground clearance at full load (mm)165
- Approach Angle (°)20
- Departure Angle (°)23
- Minimum turning radius (m)5.2
- Door opening methodswing door
- Number of doors (pcs)5
- Number of seats (pcs)5
- Fuel tank capacity (L)40
- Cargo capacity (L)367-1192
- Curb weight (kg)1225
- Maximum Gross Vehicle Mass (kg)1660
Engine
StandardOptional-None
- Engine ModelEA211-DMB
- Displacement (mL)1498
- Engine displacement (L)1.5
- Intake typeNaturally aspirated
- Engine layoutHorizontal mounting
- Cylinder arrangementL
- Number of cylinders (pcs)4
- Number of valves per cylinder (pcs)4
- Gas distribution mechanismDOHC
- Maximum power (Ps)113
- Maximum power speed (rpm)6000
- Maximum torque speed (rpm)3900
- Maximum net power (kW)83
- Fuel typeGasoline
- Fuel gradeGrade 92
- Fuel supply methodMulti-point fuel injection
- Cylinder head materialAluminum alloy
- Cylinder block materialAluminum alloy
Transmission
StandardOptional-None
- Number of gears5
- Transmission typeManual Transmission (MT)
- Abbreviation5-speed manual transmission
Chassis steering
StandardOptional-None
- Drive typeFront engine front drive
- Front suspension typeMacPherson type independent suspension system
- Rear suspension typeTorsion beam type independent suspension
- Power steering typeElectric power steering
- Body structurecarrying
Wheel brake
StandardOptional-None
- Front brake typeVentilated disc
- Rear Brake TypeDisc
- Parking brake typeHandbrake
- Front tire specification205/60 R16
- Rear Tire Size205/60 R16
- Spare tire sizeNot full size
Passive safety
StandardOptional-None
- Driver and passenger airbagMain ● / Sub ●
- Front/Rear side airbagsFront ○ / Rear -
- Front/Rear Head Airbag (Curtain)Front ○ / Rear ○
- Tire pressure monitoring function● Tire pressure alarm
- Tires that maintain pressure-
- Seat Belt Not Fastened Reminder● Front row
- ISOFIX child seat connector●
- ABS anti-lock system●
- Brake force distribution (EBD/CBC etc.)●
- Brake Assist (EBA/BAS/BA etc.)●
- Traction control (ASR/TCS/TRC etc.)●
- Body Stability Control (ESC/ESP/DSC etc.)●
Active safety
StandardOptional-None
- Lane Departure Warning System-
- Active braking/active safety system-
- Fatigue driving warning-
Driving control
StandardOptional-None
- Driving mode switching-
- Engine start-stop technology●
- Energy recovery system●
- Automatic parking-
- Hill Assist●
- Hill Descent Control-
Driving hardware
StandardOptional-None
- Front / Rear Parking Radar-
- Driver assistance systems● Reversing camera
Driving functions
StandardOptional-None
- Cruise system-
- Satellite navigation system-
- Navigation road condition information display-
- Lane Keeping Assist-
- Lane Keeping Assist System-
Exterior/Anti-theft
StandardOptional-None
- Wheel material● Alloys
- Power Tailgate-
- Roof luggage rack●
- Electronic Engine Immobilizer●
- Interior central locking system●
- Key type● Remote key
- Keyless Start System-
- Keyless entry function-
Exterior lights
StandardOptional-None
- Low beam light source● Halogen
- High beam light source● Halogen
- LED Daytime Running Lights-
- Adaptive headlights-
- Automatic headlights-
- Front fog lights-
- Adjustable headlight height●
- Headlights Delay Off-
Sunroof/Glass
StandardOptional-None
- Sunroof typeOpenable panoramic sunroof
- Front and rear electric windowsFront ● / Rear ●
- One-touch window up and down function● Entire vehicle
- Window anti-pinch function●
- Car interior mirror● Driver's seat + light bulb ● Passenger seat + light
- Rear wiper●
- Rain Sensor Function-
Exterior mirror
StandardOptional-None
- Exterior mirror function● Electric adjustment ● Side mirror heating
Screen/System
StandardOptional-None
- Center Console Color Screen● Touchscreen LCD
- Central Control Screen Size● 8 inch
- Bluetooth / Hands-free phone●
- Phone connectivity/mirroring● Supports CarPlay ● Supports CarLife
- Voice Recognition Control System-
Smart configuration
StandardOptional-None
- Internet of Vehicles●
- 4G/5G network● 4G
- OTA update-
Steering wheel/interior mirror
StandardOptional-None
- Steering wheel material● Plastic
- Steering wheel position adjustment● Manual up-down + forward-backward adjustment
- Gear type● Mechanical gear shift
- Multifunctional steering wheel-
- Steering control-
- Steering wheel heating-
- Steering wheel memory-
- On-board computer display screen● Monochrome
- Full LCD dashboard-
- LCD instrument size-
- Interior rearview mirror function● Manual dimming
In-car charging
StandardOptional-None
- Multimedia / Charging Port● USB ● Type-C
- Number of USB/Type-C ports● Front 3/Rear 2
- Mobile phone wireless charging feature-
Seat configuration
StandardOptional-None
- Seat material● Fabric ○ Leather/fabric combination
- Main seat adjustment method● Forward-backward adjustment ● Backrest adjustment ● Height adjustment (2 directions)
- Passenger seat adjustment method● Forward-backward adjustment ● Backrest adjustment
- Driver/Passenger Seat Electric Adjustment-
- Front seat functions-
- Electric seat memory function-
- Passenger Rear Seat Adjustment Button-
- Second row seat adjustment-
- Rear seat folding type● Proportionally recline
- Front/Rear Center ArmrestFront ● / Rear -
- Rear cup holder-
Audio/Interior lighting
StandardOptional-None
- Speaker brand name-
- Number of speakers● 4 speakers
- Interior ambient lighting design○ Monotone
Air conditioner/refrigerator
StandardOptional-None
- Air conditioning temperature control method● Manual air conditioning
- Rear independent air conditioner-
- Rear seat air vents●
- Temperature zone control-
- Car Air Purifier-
- In-car PM2.5 filter●
Optional package
StandardOptional-None
- Exterior colorSunroof and Safety Package
